All Copper Traditional Scottish Double Pot Stills With Copper Spirits Safe
4000L + 4000L All Copper Traditional Scottish Double Pot Stills with Copper Spirits Safe and Working Platform offered by China leading manufacturer
The double pot still includes a wash still and a spirit still. This type of still is professional whiskey distilling equipment.
First, the wort is put into the wash still for the first distillation to get a low-alcohol wine of about 20 degrees.
Then put the low-alcohol wine into the spirit still for the second distillation to get the wine to about 75 degrees.
This is original whiskey.
|
Product Name |
Boben Whisky Pot Still |
|
Material |
Red Copper/SS304 |
|
Size |
4000L (Customizable) |
|
Heating |
Steam |
|
Parts |
Boiler, Lyne arm, Condenser, Spirit safe, Stand, Pump, CIP system |
|
Option |
Collecting tanks, Platform |
|
Application |
Whisky |
4000L+4000L-Double Pot Still from China manufacturer
Parameter：
| Structure: | Boben-Pot still is 2x still pot, 1x gooseneck(helmet),2x condenser, 2x parrot outlet(spirit safe), liquor collecting tank, and support frame(leg). The system can be equipped with CIP pumps and CIP pipes. |
| Useage： | It is mainly used for the production of whiskey or stripping still. |
| Working Capacity： | From 100L~15000L customizable |
| Heating Method： | Steam/Electric heating/Gas burner/Direct fire optional |
| Voltage Supply： | 110/208/200/220/240/380/400/415/460/480/600V 3phase 50/60Hz,Special voltages can be customized |
| Certification of Motor： | UL/CSA/CE/IECEX/ATEX option |
| If heated by electrical： | CE/IECEX/ATEX/NEPSI certified electric heating elements are available |
| Material： | Stainless steel 304/ Stainless steel 316L/ C12200 copper/glass optional |
| Control section： | Manual/semi-automatic /PLC control/fully automatic control optional |
Welcome to our site, if you need help simply reply to this message, we are online and ready to help.
Introduction Of Raw Material For Making Whiskey:
Whisky (Whisky) is an alcoholic beverage made of barley, rye, oats, wheat, corn and other grains as raw materials, which are fermented and distilled in oak barrels for aging and blending. , After being aged in oak barrels for many years, it is formulated into a strong distilled spirit of about 43 degrees.
Barley, wheat, corn, and rye are the main raw materials. Traditionally, only whisky made from barley is distilled separately, and other grains are mixed and distilled in different combinations and proportions.
Single malt whisky refers to whisky distilled from barley malt in the same distillery.
The flavor of the raw material itself:
Barley: Malt, Cereals, Biscuits
Corn: Sweet, spicy, fatty.
Rye: pepper, multi-spice, palate part contributes to the taste of dried fruit
Wheat: Melon, honey, especially in bourbon to balance other overpowering flavors.
Water: hard water, soft water, water rich in peat, heather, calcium, magnesium, etc., deionized water
peat.
Why Choose Boben Whisky Distilling Equipment,
① As an industry-leading supplier of whisky distillation equipment.basically, the raw material Boben Whisky Distillery Equipment made of is high stnadard food grade Stainless Steel 304 and red copper CU to meet request, international standard and worldwide certified to enter different countries, it's safe to use for alcohol & beverage industry when making whisky liquors. Boben factory has CE Certificates for whiskey distillery equipment as well as our other products such brewery system, fermenter, brite tank,stainless steel tanks etc.
② Next, Boben products are all manully hammered, welded,polished by each individual workers, workers with good craftmanship in this industry , some are copper welding skillful workers to make sure our copper and stainless steel are perfect to meet customer's whiskey distillery to Guarantee equipment use and aesthetics.
③ Boben factory always online for free consulting service include whisky distillation solutions and other products you may interested.Boben Light Industry manufacturer,specializing in whisky, brandy, vodka, GIN, rum, rice wine distillation equipment, liquor optimization distillation equipment, pure dew essential oil distillation equipment, and the design of whisky production lines, Manufacturing, installation, commissioning and other turnkey projects.
④ At Boben Light Industry we offer you not only expertise but also years of experience with tank construction – we know exactly what will work for your business needs. We are happy to design a custom stainless steel still and tank that is perfect for both safety purposes as well as efficiency!
